Link G4X Atom EMS ECU Stand Alone Engine Management
WE HAVE PLUG AND PLAY APPLICATIONS AVAILABLE, SUCH AS 1UZ! Please contact us with your build and we can offer adapter harnesses
This works on UZ engines, and there is a built in 1UZ non-VVTi start up base map. Great budget oriented option if you only need the bare minimum standalone option. Capable of running only in wasted spark and batch fire injection on a V8. Full sequential operation would require a Storm at minimum.
Please note free shipping is in the USA lower 48 states only. Please contact us with a shipping quote to your location if you are outside the USA or are in Hawaii/Alaska.
- Shipping info
We deliver worldwide
- Payment methods
The Link G4X AtomX ECU is the latest version of Link's entry-level ECU. Don't let its size fool you however, the AtomX has expanded data logging and uses the same microcontroller as the entire G4X range! It is more responsive and has higher bandwidth than its G4+ Atom II predecessor.
G4X features 512 megabytes of logging at 32bit using up to 250 channels, each limited to up to 1kHz per channel (by the Operating System), with a maximum of 100k Samples/sec.
G4X features 8 x faster communications speed, allowing you to download logs 8 x faster and pushes all the logging quickly up to a new and improved PCLink – available for download below in the features tab.
The AtomX can control up to 2 rotors or 4 cylinders with sequential injection and direct spark. Or, it can be used for up to eight cylinders using batch fire. Now featuring Knock Control.
This makes it ideal for naturally aspirated engines that just need a re-tune and don't need all the extra sensors and features that come with our higher level ECUs.
The AtomX is ideal for:
1-12 Cylinder Distributed
2-8 Cylinder Wasted Spark
1-4 Cylinder Direct Spark
Odd Fire Engines
2-Stroke Engines
Configurable Firing Order
Configurable TDC Points (for odd fire)
SPECS
Inputs:
2 x Digital inputs
2 x Temperature inputs
3 x Analog inputs
2 x Trigger inputs
1 x Knock Input
Outputs:
4 x Injector drives
4 x Ignition drivers
4 x Auxiliary outputs*
+5V Sensor power supply
*unused ignition drives can be used as additional Aux
outputs
Communications:
1x CAN bus
1x USB tuning connection
1 x thirty four pin, waterproof connector
Upgraded Communications Chip
Misc:
Comes loaded with all of Link ECU's standard features.
512MB of logging memory
20 general purpose tables
Runs on PC Link software for G4X
Physical:
Dimensions: 90mmL x 130mmW x 45mmH (without loom)
Weight: 180 grams
What's in the box:
The AtomX ECU is supplied with a USB tuning cable, mounting bracket and four Link ECU stickers.
- Link External MAP SensorNo thanks, Yes, 3 bar, 101-0164, Yes, 2.5 bar, 101-0163, Yes, 4 bar, 101-0165, Yes, 5 bar
- Link IAT SensorNo, Yes + steel weld boss 101-0045 + 47, Yes + aluminum weld boss 101-0045 + 46, Yes, 101-0045
- Link Ethanol SensorNo, Yes, with -6 AN fitting 101-0034
- Link Oil/Fuel 10 bar Pressure SensorNo, Add one please! 101-0080, Add both!!
- Link Coolant Temp SensorNo, Yes, 101-0076
- Link Boost Control SolenoidNo, Yes, 3 port 3BCS, Yes, 4 port 4BCS
