XAT 2JZGE Crown Turbo Manifold 1JZGE VVTi Altezza IS300 Aristo GS300

XAT 2JZGE Crown Turbo Manifold 1JZGE VVTi Altezza IS300 Aristo GS300

Because of poor fitment of other manifold options on the market, we decided to develop a new exhaust manifold specifically for our JZS155 hardtop Crowns! This manifold puts the turbo in just the right position to not interfere with the throttle Y-pipe that goes over the engine, so you can retain the stock intake manifold still. Larger turbo setups may require further modifications, which you can expect with larger turbo setups anyways.

304 stainless steel, 2mm thick runners, 1 5/8" runner ID and a 3 year warranty!

Please note that while we try to keep the T4 version in stock, there may be a 4-6 week wait time for them to be custom made.

This fits 1JZGE VVTi heads, but not 1JZGE non-VVTi heads, which are unique and do not have an interchangeable bolt pattern. Turbo and turbo kit not included with this listing, but we can build you one!

Wastegate piping is included, however the base manifold does leave off the flange for you to weld the matching flange for your wastegate. We also keep in stock flanges for the most popular wastegates, so we can include and/or weld that up for you!

Not rated yet
XAT Racing
  • $990
In stock(1 item available)
    • SKU
    • Weight
      17 lbs
  • Manufacturer
    XAT Racing
  • Turbo Footprint
    T4 divided, T4 undivided, T3 divided, T3 undivided, V-band (we will need the matching v-band for your turbo)
  • Wastegate Flange Welded
    44/45/46mm MV-R / Hypergate, 38/40mm MV-S / Compgate, Other (contact us), None
  • Ceramic Coating
    None, raw finish, Black ceramic (adds 1-2 weeks)
  • Screamer Wastegate Pipe
    Yes, 44/46mm fitment, 44/46mm, ceramic coated black, Other (contact us), None
  • Wastegate
    TurboSmart 45mm Hypergate, TurboSmart 40mm Compgate, None

Most product ships from either the manufacture or largest wholesale location to pass the saving to you. Most orders will ship via UPS, as we will be able to provide the best rates and have had the least issues when using UPS.

IF YOU DO NOT LIKE THE AUTOMATED SHIPPING CALCULATOR'S RATES, PLEASE CONTACT US AND WE CAN GET YOU A BETTER ONE! Especially for anyone outside the USA, please contact us with a list of parts you'd like to order, and where you are located.

We accept the following payment methods:

Also Venmo and unmarked nonsequential dollar bills

  • Fitment Type
    Vehicle Specific
Toyota/LexusLexus GS/Aristo1992-1997 S1472JZ-GE/2JZ-GTE 3.0 I6
Toyota/LexusLexus GS/Aristo1998-2005 S1602JZGE/2JZGTE 3.0 I6 (98-05) JZS160/JZS161
Toyota/LexusLexus IS/Altezza1998-2005IS300 2JZGE 3.0 I6 JCE10
Toyota/LexusCrown (hardtop)1995-19992JZ-GE 3.0 I6 Royal Saloon, Royal Saloon G, Royal Touring (JZS155)
Toyota/LexusCrown (hardtop)1995-19991JZ-GE 2.5 I6 Royal Saloon (JZS151)
Toyota/LexusChaser, Mark II, Cresta1996-2001 X1001JZ-GTE VVTi 2.5 I6 turbo Tourer V
Toyota/LexusChaser, Mark II, Cresta1996-2001 X1001JZ-GE VVTi 2.5 I6 Tourer S, Avante/Grande
Toyota/LexusCrown Majesta1995-1999 S1502JZ-GE 3.0 I6 (JZS155)
Toyota/LexusLexus SC/Soarer1992-2000 Z302JZ-GE 3.0 I6 JZZ31
Toyota/LexusSupra1986.5-1992 A701JZ-GTE 2.5 TT I6 JDM 1990-1993 JZA70
